10.1 Inch Thin Flat LCD PC Monitor:
Size: 10.1 inch
Panel Type: Industrial Touch Screen LCD Display
Resolution:10.1 inches(1280*800)
Interface: optional non-touch(VGA+DC, DVI+VGA+DC, HDMI+VGA+DC),
Resistive touch(VGA+DC+USB, DVI+VGA+DC+USB, HDMI+VGA+DC+USB)
Brightness: 250-350cd/m2 (support higher, please contact us for details).
Response time: 5ms
Display Color: 16.7M (8-bit)
Viewing angle: 80/80/80/80
touch screen parameters
Touch technology: Resistive technology (single touch).
Do you need to install the driver: Yes (download from the website: www.EETI.com).
Effective touch recognition: >1.5mm.
Touch mode: USB 2.0, 3.0.
Theoretical hits: over 50 million.
Touch principle: pressure sensing, touch force: 45g~250g.
Surface hardness: physical toughening, Mohs 7 explosion-proof glass.
Other parameters
Input power: 100-220V AC 50/60H
Output power: 24V 3-5A
Power consumption of the whole machine: <26W
Standby power consumption: <3w
Working temperature: -20℃-60℃
Working humidity: 0%-90% (neither cold or hot)
Storage temperature: -40℃-85℃
Storage humidity: 10%-95% (cold without doubt)
With HDMI+VGA+DC+touch USB
If you need other interfaces and other questions, please contact our customer service. Thank you
Datasheet for our 3mm bezel aluminum 10/12/15/17 inch thin flat lcd PC monitor:
Size:10/12/15/17 inch
Panel Type:Industrial Touch Screen LCD Monitor
Resolution:10/12/15 inch (1024x768 ),17 inch (1280*1024)
Interface:Optional VGA,DVI+VGA,HDMI+VGA
Luminance|:250nit-400nit(The default is 300cd/m2)
Response time:5ms
Display colors:16.7M(8-bit)
View angle:80/80/80/80
Installation method
Easy to install, one-key boot
1. Embedded installation
① The cabinet needs to be opened before installation, and the opening size should be slightly larger than the opening size specified by the product.
②Place the product in the embedded installation opening reserved on the installation panel.
③There are two square holes on both sides of the device. When installing, use one end of the buckle to buckle the square hole, and the screw head on the buckle to hold the cabinet.
Then tighten the screws. The installation method of the other three prescription holes is the same to complete the embedded installation.
2. Wall-mounted installation
① Fix the wall bracket A on the wall with expansion screws.
②The wall bracket B is installed on the back of the all-in-one with screws.
③ Insert the back bracket of the all-in-one into the wall bracket to complete the installation.
FAQ (Frequently Asked Questions)
Q: How to install the touch calibration program?
A: After connecting the monitor to your host, according to your host system, go to the website to download the corresponding touch driver, and then install the touch driver according to the prompts. After the installation is successful, perform the program screen calibration. If you buy a capacitive touch monitor, you can directly connect the touch USB cable.
Q: Is the machine waterproof?
A: Yes, the panel is waterproof, but it is not recommended to be immersed in water.
Q: What is the standard installation method?
A: Embedded, wall-mounted
Q: Does it support desktop installation?
A: Yes, but you need to buy a desktop stand
