Product Details
Place of Origin: Guangdong, China
Brand Name: TOUSEI
Model Number: TS156
Payment & Shipping Terms
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: box in carton
Payment Terms: Western Union, T/T, MoneyGram
After-sales Service Provided: |
Video Technical Support, Free Spare Parts, Online Support |
CPU: |
J1800/J1900/i3/i5/17 |
Printer: |
58mm 80mm Thermal Printer |
Wireless And Communication: |
2G/3G/4G, Wi-Fi, Blue Tooth |
Main Screen: |
15.6" Touch Screen |
Touch Screen: |
10 Points Capactive Touch |
Resolution: |
1920*1080 /1366*768 |
Warranty: |
1 Year |
Touch Screen Type: |
Capacitive Screen |
Function: |
SDK |
Operation System: |
Android 11 / Windows 10 / Linux |
Hard Disk Capacity: |
J1800/J1900/i3/i5/17 |
After-sales Service Provided: |
Video Technical Support, Free Spare Parts, Online Support |
CPU: |
J1800/J1900/i3/i5/17 |
Printer: |
58mm 80mm Thermal Printer |
Wireless And Communication: |
2G/3G/4G, Wi-Fi, Blue Tooth |
Main Screen: |
15.6" Touch Screen |
Touch Screen: |
10 Points Capactive Touch |
Resolution: |
1920*1080 /1366*768 |
Warranty: |
1 Year |
Touch Screen Type: |
Capacitive Screen |
Function: |
SDK |
Operation System: |
Android 11 / Windows 10 / Linux |
Hard Disk Capacity: |
J1800/J1900/i3/i5/17 |
Features:
* 1. CPU: High Performance and Energy Saving CPU Intel Celeron J1800/J1900/CORE I5 3317U/2840/3710
* 2. Memory: DDR3 RAM 2GB/4GB/8GB optional
* 3. Hard Disk: SSD ROM 32GB / 64GB / 128GB / 500GB optional
* 4. Screen: 15.6 inch TFT LCD Screen(Highlight LED Backlight)
* 5. Touch Screen: 4 wire resistive or 10 Points Capacitive multi-touch screen optional
* 6. Built-in Smart Heat Sinks Cooling System
* 7. Operating System: Windows 7,8,10
* 8. Full Tablet Style, Single / Double Screen are available
* 9.The shell with perfect handfeel, which is wear-resistant and magnificent in appearance
Windows System Specification
|
|
|
|
|
||||
Mainboard
|
|
|
|
|
||||
CPU
|
Intel J1800 / J1900 / i3 / i5 / i7
|
|
|
|
||||
RAM (memory)
|
DDR3 4G / 8G / 16G
|
|
|
|
||||
Hard Disk (SSD)
|
64G / 128G / 256G
|
|
|
|
||||
Operating system
|
Windows 7, Windows 10
|
|
|
|
||||
Screen
|
|
|
|
|
||||
Main screen
|
15.6 inch
|
|
|
|
||||
Resolution
|
1920*1080 or 1366*768
|
|
|
|
||||
Customer display
|
Optional
|
|
|
|
||||
Wifi
|
Support 802.1 protocol
|
|
|
|
||||
External I/O
|
|
|
|
|
||||
USB
|
ports (outside: 2pcs, inside: 4pcs)
|
|
|
|
||||
VGA
|
1*VGA port
|
|
|
|
||||
COM
|
1*COM port
|
|
|
|
||||
Lan
|
1*Lan port
|
|
|
|
||||
Audio
|
1 *Mic input, Audio output*1
|
|
|
|
||||
LPT printer interface
|
1 port (optional)
|
|
|
|
||||
Optoinal
|
|
|
|
|
||||
Customer display
|
VFD 2 lines customer display optional
|
|
|
|
||||
MSR (card reader)
|
Track (1+2+3)
|
|
|
|
||||
Language
|
Chinese, English, Spanish, French......
|
|
|
|
Android System Specification
|
|
|
|
|
||||
Main board
|
|
|
|
|
||||
CPU
|
RK3288/RK3568
|
|
|
|
||||
RAM (memory)
|
2G
|
|
|
|
||||
Hard Disk Capacity (SSD)
|
16G
|
|
|
|
||||
Operating system
|
Android 8/10/Linux
|
|
|
|
||||
External I/O
|
|
|
|
|
||||
USB
|
6 ports (outside: 2pcs, inside: 4pcs)
|
|
|
|
||||
RJ45
|
1*RJ45 port
|
|
|
|
||||
TF card
|
1* TF card
|
|
|
|
||||
UART4
|
1*UART4
|
|
|
|
||||
Cash box
|
1*Cash box
|
|
|
|
||||
Audio
|
1*Mic input, Audio output*1
|
|
|
|
||||
DCin. 12V 5A
|
1*
|
|
|
|
